HikVision 8 Port Fast Ethernet Smart POE Switch (DS-3E1310P-SI)
Rp2.482.462
- 8 × 100 Mbps PoE RJ45 port, 2 × gigabit combo.
- IEEE 802.3at/af standard for PoE ports.
- Network topology management, alarm push, network health monitor.
- 6 KV surge protection for PoE ports.
- AF/AT camera can reach up to 300 m in extend mode.
Deskripsi
Spesifikasi :
| Shell | Metal material |
| Net Weight | 1.72 kg (3.79 lb) |
| Gross Weight | 2.20 kg (4.85 lb) |
| Dimensions | 266.00 mm × 44.50 mm × 220.80 mm (10.47” × 1.75” × 8.69”) |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Storage Temperature | 40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100-240 VAC, 50/60 Hz, Max. 1.5 A |
| Installation Mode | Rack (equipped with mounting ears) |
| Max. Power Consumption | 150 W |
| Power Consumption in Idle | 5 W |
| Surge Protection | 6 KV |
| Port | 8 × 10/100 Mbps PoE port,2 × Gigabit combo |
| MAC Address Table | 16 K |
| Switching Capacity |
9.2 Gbps |
| Packet Forwarding Rate |
6.84 Mpps |
| Internal Cache | 4 Mbits |
| Power supply | |
| PoE Standard | IEEE 802.3af,IEEE 802.3at |
| PoE Power Pin | 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | PoE: Ports 1 to 8 |
| Max. Port Power | 30 W |
| PoE Power Budget | 125 W |
| Long Range |
Ports 1 to 8: up to 300 m. Long range performance may vary depend on camera model or cable condition. |
HikVision-DS-3E1310P-SI_Datasheet.pdf
